    2 1/2" Round Clearance Marker Lights

    With twist-on mounting for easy installation, Grote's 2 1/2" Round clearance marker lights fit all popular mounting and grommets.
    Grote Loading Ajax Spinner

    45812Optic Lens, 12V

    45812Optic Lens, 12V

    • 2 1/2 clearance marker light optic red 360 thumbnail
    • 2 1/2 clearance marker light optic red thumbnail
    • 45812 - drawing thumbnail

    Compare

    0 Product Added

    Compare

    Quickly compare up to 5 Grote products...

    pdf spinner


    Add more products to compare

    Technical specifications
    • Material: Polycarbonate Housing, Polycarbonate Lens
    • Color: Red
    • Lens Color: Red
    • Amperage: .33A
    • Mounting Type: Grommet, Bracket
    • Connection Type: PL-10
    • Size: 2½"
    • Regulations: FMVSS 108
    • Functions: P2, PC
    • Bulb: 2 CP
    • VMRS: 034-004-021
    • Diameter: 2.5"
    • Bulk Pack #45812-3: 48
    Features & benefits
    • Features a 12,000+ hour bulb
    • 12-volt version features a 12,000+ hour bulb
    • Hermetic lens to housing seal
    • Optic version only, meets PC function only when mounted at a 45° angle
    • Twist-on mounting for easy installation
    • Fits all popular mountings and grommets

    Replacements, Tools & Accessories

    Bracket Twist-In Surface Mount Bracket, Gray
    43690
     Bracket Theft-Resistant Mounting Flange
    43160
     Bracket Theft-Resistant Mounting Flange & Pigtail Retention Cap For 2 1/2" Round Lights, Mounting Flange, Black
    43162
     Bracket Theft-Resistant Mounting Flange & Pigtail Retention Cap For 2 1/2" Round Lights, Mounting Flange, Chrome
    43163
     Bracket Mounting Bracket For 2" & 2 1/2" Round Lights, (2 25/32" Hole)
    43512
     Bracket Mounting Bracket For 2" & 2 1/2" Round Lights, (3" Hole)
    43522
     Bracket Bar Lamp Bracket For 2" & 2 1/2" Round Lights, Black
    49140
     Bracket Mounting Bracket With Grommet For 2 1/2" Round Lights, Gray
    93750
     Bracket Twist-In Surface Mount Bracket For 2" & 2 1/2" Round Lights, Gray
    42180
     Bracket Snap-In Mounting Flange For 2 1/2" Round Lights, Mounting Flange, Gray
    42170
     Grommet 2 25/32" Hole Grommet, Open Grommet
    91400
     Grommet 3" Hole Grommet, Open Grommet
    91410
     Grommet 2 25/32" Hole Grommet, Closed Back Grommet
    92070
     Grommet Grommet For Surface Or Flush Mount Lights, Open Grommet
    91890
     Grommet 45º Angled Beveled-Edge Mounting Grommet, Open Grommet
    91880
     Pigtail Sealed Marker Light Pigtail, Double Seal, 6" Long, Ground Return
    66851
     Pigtail Sealed Marker Light Pigtail, Double Seal, 6" Long, Chassis Ground
    66850
     Pigtail Sealed Marker Light Pigtail, Double Seal, 6" Long, Ring Terminal Ground, Blunt Cut Wire
    67001
     Pigtail Sealed Marker Light Pigtail, Single Seal, 6" Long, Ring Terminal Ground, Blunt Cut Wire
    67050
     Pigtail Sealed Marker Light Pigtail, Single Seal, 6" Long, Chassis Ground, Slim-Line .180 Male
    66800
     Pigtail Sealed Marker Light Pigtail, Single Seal, 6" Long, Chassis Ground, Standard .180 Male
    66840
     Pigtail Sealed Marker Light Pigtail, Single Seal, 6" Long, Ground Return
    66801
