Compact LED Beacons

Grote's Compact LED Beacons combine the key advantages of advanced LED technology with a durable polycarbonate housing. Engineered for reliability and long service life, they are ideal for applications where a durable, low-profile warning light is required.

Grote Loading Ajax Spinner

79184Green LED Compact Base - Permanent Mount

79184Green LED Compact Base - Permanent Mount

  • 79184 thumbnail

Compare

0 Product Added

Compare

Quickly compare up to 5 Grote products...

pdf spinner


Building product information

Loading, please wait

Please wait a moment...

Add more products to compare

Technical specifications
  • Color: Green
  • Operating Temperature: -40°C to +55°C
  • Voltage: 12/24V
  • Height: 4.18"
  • Class: Class II
  • Mounting Type: Permanent/Pipe
  • Connection Type: Blunt Cut
  • Lens Color: Green
  • Amperage: .4A
  • Size: Compact
  • VMRS: 034-006-056
  • Material: Polycarbonate
  • Outside Diameter: 4.28"
  • Package Type: Full Color Box
  • # of Wires: 3
  • Wire Length: 457 mm
  • Warranty: 5 Years
  • Wire Gauge: 18 GA
Features & benefits
  • SAE Class I or II beacons in a compact design
  • Permanent mount base with optional ½" pipe mount or magnetic mount with aux power cord
  • Ideal for mirror mount applications or where low-profile lamps are beneficial
  • Replaceable polycarbonate lens – 98513
  • 12 customer selectable flash patterns in either of two phases, plus steady-on
  • S-Link™ 2.0 System allows for flash pattern synchronization with up to ten other S-Link compatible units (for hardwire models only)
  • Polycarbonate lens and base (Ultrasonic welded); Polarity protected
  • Three-hole, permanent mount and magnet mount with pattern select aux. plug
Find a Local Distributor

Replacements, Tools & Accessories

Accessory replacement led beacon lens
98513
 Accessory 93604
93604
 Accessory Heat Shrinkable Butt Connectors - Polyolefin, 22 - 18 Gauge, 15pk
84-3150
 Accessory Multi Crimp Cut And Strip Tool
83-6512
