    Hi Count® Rectangular LED Stop Tail Turn Lights

    Grote Loading Ajax Spinner

    G4502Red

    G4502Red

    • hi count rectangular led stop tail turn light red 360 thumbnail
    • hi count rectangular led stop tail turn light red thumbnail
    • thumbnail

    Compare

    0 Product Added

    Compare

    Quickly compare up to 5 Grote products...

    pdf spinner


    Add more products to compare

    Technical specifications
    • Material: Polycarbonate Housing, Polycarbonate Lens
    • Color: Red
    • Lens Color: Red
    • Housing Color: Black
    • Voltage: 12V
    • Amperage: .07A-.5A
    • Mounting Type: Grommet, Bracket
    • Connection Type: Female Pin
    • Regulations: FMVSS 108
    • Functions: P2, S, T, I
    • VMRS: 034-002-059
    • Bulk Pack #G4502-3: 0
    Features & benefits
    • 15 Diodes
    • LED instant-on feature provides early stop warning for trailing motorists
    • Meets photometric requirements for front, park and turn
    • Vertical or horizontal mount
    • Potted for total circuit-board protection against vibration and corrosion
    • Hermetically-sealed polycarbonate lens and body
    • Standard female pin connection provides easy retrofits

    Replacements, Tools & Accessories

    Grommet Grommet For Rectangular Lights, Mounting Grommet, Black
    94180
     Pigtail Stop Tail Turn Three-Wire Plug-In Pigtails for Female Pin Lights, 8" Long, Ground Return, Slim-Line .180 Male
    66825
     Pigtail Stop Tail Turn Three-Wire Plug-In Pigtails for Female Pin Lights, 11 1/2" Long, Chassis Ground, Blunt Cut Wires
    67000
     Pigtail Stop Tail Turn Three-Wire Plug-In Pigtails for Female Pin Lights, 6" Long, Chassis Ground, Slim-Line .180 Male
    66812
     Pigtail
    67090
