DLS306 LED Light
The DLS306 Mini-Comet™ offers maximum light output in a compact design, ideal for both interior and exterior mounting on emergency and utility vehicles. Featuring six Star Generation IV LEDs and a variety of selectable flash patterns, this unit ensures high visibility and flexibility in any situation.
DLS306-AGAmber/Green, 10-30V DC
DLS306-AGAmber/Green, 10-30V DC
-
DLS306C-AG
Compare -
DLS306-AG
Compare
Technical specifications
- Current Draw: 0.9 A @ 12 VDC
- Mounting: Surface Mount
- Color: Amber/Green
- Voltage: 10-30V DC
- Weight: Less than 1 lb
Compare
0 Product Added
Technical specifications
- Current Draw: 0.9 A @ 12 VDC
- Mounting: Surface Mount
- Color: Amber/Green
- Voltage: 10-30V DC
- Weight: Less than 1 lb
Features & benefits
- Maximum light output in a minimum package
- Six Star Generation IV LEDs
- Twelve different selectable flash patterns in either of two phases, plus Steady-On
- NEW steady burn override option
- Single color flashing, steady White override
- Both colors flashing, steady White override
- Both colors flashing, White steady while other color remains flashing
- LED colors are now intermixed, allowing truer dual color effect
- S-Link System™ synchronizing capabilities with other Star LED units
- Fully encapsulated circuitry within the housing for vibration and water resistance
- Lens has diffusing optics for wider coverage
- Can mount just about anywhere and mount in any direction
- Built-in flasher
- Interior/exterior mount
- Kit includes a snap-on polycarbonate Black (standard), Chrome, or White bezel that will hide screw heads for a clean install
Viewing 0 / 24 Products
Filter by
| Products # | Image | Color | Voltage | Mounting |
|---|
Additional information
Model List
| Model |
|---|
| DLS306 |
| DLS306C |
Replacement Parts
| Description | Part Number |
|---|---|
| Black bezel | P30019-144B |
| Chrome bezel | P30019-144P |
| White bezel | P30019-144W |
