67271Rear Sill Adapter

67271Rear Sill Adapter

  • Cut-To-Fit® Wire Harness Systems, Rear Sill Adapter thumbnail
  • 67271 - drawing thumbnail

Compare

0 Product Added

Compare

Quickly compare up to 5 Grote products...

pdf spinner


Building product information

Loading, please wait

Please wait a moment...

Add more products to compare

Technical specifications
  • Wire Material: GPT
  • Connector Side Two: Double Slim-Line .180" Female Bullet
  • Connector Quantity: 1
  • Connector Side One: Slim-Line .180" Male Bullet
  • Color: Black
  • Wire Gauge: 14 GA
  • Connection Type: Slim-Line .180" Male Bullet, Double Slim-Line .180" Female Bullet
  • Length: 2' (24")
  • Wire Length: 23"
  • Pack Quantity: Individual (6 per carton)
  • VMRS: 034-004-023
  • Product Type: Harness
  • # of Wires: 1
  • Style: Jumper Harness
  • Product Line: Cut-To-Fit®
  • Warranty: 1 Year
Features & benefits
  • This jumper can be plugged directly into the double slim-line plugs
  • Adapts to the standard Grote Utlra-Blue-Seal® rear sill and main harness
  • Part number 67271 plugs into elbow-style rear sill, making a corrosion-proof connection
  • Mates with the Grote seven pin receptacle (nose box) with the use of either the 67260 adapter or the 67250
Find a Local Distributor

Replacements, Tools & Accessories

Accessory Cut-To-Fit® Wire Harness Systems, Rear Sill Adapter
67271
