Crimp Solder & Seal Butt Connectors

Grote Loading Ajax Spinner

83-292922 - 18 Gauge

83-292922 - 18 Gauge

  • Crimp Solder & Seal Butt Connectors, 20 - 18 Gauge, 100pk thumbnail

Compare

0 Product Added

Compare

Quickly compare up to 5 Grote products...

pdf spinner


Building product information

Loading, please wait

Please wait a moment...

Add more products to compare

Technical specifications
  • Material: Polyolefin
  • Color: Red
  • Gauge: 22-18 GA
  • Connection Type: Butt
  • Operating Temperature: -55°C (-67°F) to 110°C (230°F)
  • Standards: cUL
  • Functions: Crimp, Solder & Seal
  • Pack Quantity: 100
  • Strength: 2200 PSI
  • Shrink Ratio: 3:1
  • Product Type: Butt Connector
  • ROHS: Yes
  • UL Listed: Y
  • Voltage Rating: 600 V
  • Warranty: 1 Year
Features & benefits
  • Protects splices from water, corrosion, salt and moisture, provides strain relief
  • Protects against added vibration in rugged environments
  • Completely insulates and protects electrical connections
  • Seamless butt connectors & brazed-seam rings & spades prevent unwanted opening of the connector barrel.
  • Color-coded tubing with wire gauge imprint provides easy identification of the correct part for the job
  • UL listed
  • Lead-free solder has greater surface tension
  • Solder stays in place which provides greater tensile strength than other solder sleeves
  • Solder sleeves are pre-fluxed to clean metals & provide a quality solder termination
  • New solder sleeves are Tin & Bismuth alloy
  • 45° barrel allows installer to see wire is fully inserted and wire is crimped to terminal
  • RoHS compliant; better for the environment
