Dual Wall 3:1 Flexible Adhesive Lined Heat Shrink Tubing

Flexible Dual Wall is an adhesive lined heat shrink tubing that provides moisture resistance, strain relief and electrical insulation for splices, terminations, breakouts and mechanical connections. The outer wall is semi-rigid, cross-linked polyolefin, while the inner wall is an adhesive lining that flows with the application of heat. This moisture resistant tubing provides flexibility to insulate and protect irregular shape products. It also provides rugged protection from chemicals, abrasion, vibration and flexing.
Grote Loading Ajax Spinner

Compare

0 Product Added

Compare

Quickly compare up to 5 Grote products...

pdf spinner


Add more products to compare

Technical specifications
  • Material: Cross linked Polyolefin
  • Color: Black
  • Voltage: 600V
  • Gauge: 22-18 GA
  • Operating Temperature: -40°C to 110°C (-40°F to 230°F)
  • Size: 1/8"
  • Length: 6"
  • Standards: UL E35586, CSA LR31929, MIL 23053/4, Class 3
  • Pack Quantity: 20
  • Shrink Ratio: 3:1
  • Outer Wall Construction: Flexible
  • Inner Wall Construction: Adhesive Lined
  • Moisture Resistancy: High
  • Flame Retardancy: Excellent
  • ROHS: Yes
  • Type: Dual Wall
Features & benefits
  • Shrink Ratio: 3:1
  • Industry leading dual wall, "flexible" - adhesive lined heat shrinkable tubing
  • Designed for insulating and sealing components and splices for under the hood environment
  • Inner wall has unique specially formulated "Hot Melt" adhesive that forms an outstanding barrier against fluids and moisture
  • Minimum shrink temperature 80°C (176°F)
  • Operating temperature range -40°C (-40°F) to 110°C (230°F)
  • UL E35586 & CSA LR31929 ratings
  • 600 Volt 125
  • Remains semi-flexible post heat
